Mile Marker V-12 Variable Speed Electric Winch

Mile Marker V-12 Electric Winch

Mile Marker unleashes their best performing, most innovative winches to date: the V-Series electric winches.

Featuring ground-breaking Solid-State controls (NO SOLENOIDS!), Variable Speed Line Control, Waterproof Sealing, and blazing line speeds, this winch line will prove to be the ultimate winch on the market.

A durable, dual-compound black polyurethane coating and stainless steel hardware put the finishing touches on this 12,000 pound winch that is built to handle anything you can throw at it. If you are looking for the winch with awesome looks, and unmatched performance, look no further.

"Get in Control" of your recovery, as you use the handlebar-mounted Joystick to precisely toggle the line speed needed to safely and effectively get the job done. The illuminated Joystick Control also signals crucial safety features like low battery voltage on the vehicle, as well as high-operating temperature warnings.

V-12 (77-52151) 12,000lb Winch Specifications

Rated Line Pull (single line)	12,000 lbs. (5443 kg)
Gear Train	3 Stage Planetary gear system for fast line speed
Gear Ratio	212:1
Motor	6.5 HP series wound (4.9 KW) 12V DC
Drum Size: Diameter/Length	2.5” X 9” (63.5 mm X 228.6 mm)
Cable supplied (Min break force 14,400 lbs., 6531 kg)	3/8" (9.53 mm) x 100' (30.5m) galvanized aircraft cable with replaceable hook
Overall Dimensions (LxWxH)	23.30” X 6.63” X 8.83” (591.82mm X 168.4 mm X 224.3 mm)
Total Shipping Weight	102 lbs (46.3 Kg)
Mounting Bolt Pattern	4 Bolt Pattern, 4.5” X 10” (114.3 mm X 254 mm)

V-12 (77-52151) Winch Specifications

Performance of 1st Layer.
Line Pull		Line Speed (approx.)		Motor Current
Lbs.	Kgs.	FPM	MPM	12v Amp
0	0	21	6.4	80
2000	907	14	4.3	144
4000	1814	10.4	3.2	195
6000	2722	8.5	2.6	240
8000	3629	7.4	2.3	300
10000	4536	6.6	2.0	334
12000	5443	6.1	1.9	380

Line pull and cable capacity by layer
Layer	Lbs.	Kgs.	Ft.	Meters
1	12000	5433	17	5.18
2	9600	4354	37	11.28
3	8100	3674	62	18.9
4	7000	3175	92	28.04
5	6000	2722	100	30.48

Winch Comparison Video

Watch this 17 minute educational video to: learn the differences between an electric and hydraulic winch; the differences between the H and HI Series Hydraulic Winch; and see a test comparison of several manufacturer's winches.

Click Here.. to see the video.
