40049 | Viair Automatic Deployment Air System
+1-989-755-0561 1-800-358-4751

Automatic Deployment Air System | Viair | Heavy Duty | Universal

SKU 40049

$428.95 Free Ship!

Typically ships in 2 to 3 business days.

The Viair Universal ADA System incorporates a 12-port extruded aluminum air tank to provide a compact air locker and tire inflation station using a 400C Heavy Duty compressor.

Related Products

Product Specs for Viair 40049

Ask an Expert

customer service Our Michigan based experts can help.

1.800.358.4751
Email
Hours
M-F 7:00AM - 11:00PM EST
Sat 8:00AM - 1:00PM EST

Viair 40049 Details

Overview

The Viair Automatic Deployment Air (ADA) Systems deliveres incredible performance in a compact space. Viair ADA Systems incorporate a 12-port extruded aluminum air tank to provide a compact air locker and tire inflation station using a 400C (Heavy Duty) compressor at its core. ADA Systems come complete with a pressure switch, automatic coupler, Digital Tire Inflation Kit, and a wiring harness to make the installation a plug and play process.

Universal model 40049 does not includes a brake booster mounting bracket.

Features

  • 400C Compressor
  • Extruded Aluminum Air Tank (12-port)
  • Toggle Switch
  • Air Line for Remote Mount Air Filter Installation
  • (2) Remote Mount Air Filter Relocation Fittings
  • 1/8 inch NPT Drain Cock
  • 1/4 inch NPT Safety Valve
  • (8) 1/4 inch NPT Hex Plug
  • 1/4 inch NPT Sealed Pressure Switch (85/105 PSI)
  • (2) 1/4 inch NPT BSP Adapter
  • 1/4 inch  NPT Automatic Coupler
  • Brake Booster Mounting Bracket
  • 30 foot Inflation Hose with Automatic Couplers
  • Digital Tire Inflation Gun
  • 30-amp Delphi Connector Set
  • 60-amp Fuse Holder
  • 40-amp Fuse
  • (2) 1/4 inch Ring Terminal
  • 5/16 inch Ring Terminal
  • (3) Female Spade Terminal Connector

Specifications

  • 12-Volt
  • Permanent Magnetic Motor
  • Duty Cycle: 33% @ 100 PSI
  • Max. Working Pressure: 150 PSI
  • Amp Draw: 26 Amps
  • Min. Ambient Temp: -40° F
  • Max. Ambient Temp: 158° F
